Product Infomation

제품명		XA 인티앰프
카테고리		Integrated Amp.

.

.

Specifications

GENERALXA-INT AMPLIFIER

Output power Class A mode	2 x 1.1 Watt (@ 16 Ohm)
Output power Class A/B mode	2 x 120 Watt (@ 4 Ohm)
Max. power consumtion	350 VA
High precision volume attenuator	Custom made 3-channel conductive film potentiometer
IR remote control	yes

ELECTRONIC CIRCUITRY

Zero feedback	yes
Primary LC filter stage	yes
Secondary LC filter stage	yes
Active electronic voltage regulation (secondary)	yes

INPUTS / OUTPUTS

Asymmetrical/single ended inputs	3
Symmetrical/balanced inputs	2
Symmetrical/balanced outputs	1
Input impedance	47 kOhm
Trigger outputs (12 VDC)	2

CHASSIS AND FINISHES

Outer unibody aluminium chassis with heatsinks	18.5 kg
Inner unibody aluminium core	9.8 kg
Chassis	black powder coated
Upper and lower brackets Handles Command bar Frontpanel	black or silver anodized black or silver anodized black or silver anodized black or silver anodized wooden veener high gloss lacquer finish

DIMENSIONS / WEIGHT

Width x Height x Depth
Weight

484.5 x 190.0 x 486.0 mm
42.5 kg
