Product Infomation
 | | 제품명 | 컨피던스 60 | | 카테고리 | Main Speakers |
초대형 3웨이 플로어스탠딩 모델로써 컨피던스 시리즈의 타 모델들과 달리 24cm 우퍼가 2개 탑재되며, 2개의 15cm 미드레인지, 1개의 에소타 3 트위터가 장착된다. DDC와 DDC 렌즈는 기본. 전작의 컨피던스 C4를 대체하는 모델이지만, 대체 모델이라기고 하기엔 너무나 뛰어난 사운드의 대형 울트라급 하이엔드 스피커. |
 |  |  |  |
Ultimate performance ! Ultimate quality ! Ultimate innovation !
다인오디오의 가장 진보된 스피커 라인의 플래그십을 만나보라.
때로는 사이즈가 중요합니다. 모든게 새로워진 신형 컨피던스 라인의 플래그십 Confidence 60은 기존의 Confidence C4 모델을 뛰어넘는 스탠드형 스피커 입니다.
It’s unashamedly big; it’s unselfconscious hi-fi royalty. And it sounds like nothing else you’ve heard. Pull up a chair.
While your ears are captivated by the Confidence 60’s astonishing power, scale and detail, your eyes will probably be drawn to the single Esotar3 28mm soft-dome tweeter in the middle. Then the twin 15cm MSP midrange drivers with Horizon Surrounds. And, finally to the two 23cm MSP NeoTec Woofers.
The drivers are all new. And they’re all part of the next generation of our innovative DDC (Dynaudio Directivity Control) sound-shaping technology platform. This focuses the sound waves radiating from the speakers into a tight vertical ‘beam’ that avoids reflections from floors and ceilings while maintaining a wide horizontal image. That means a bigger sweet-spot on the couch, a happier audience, and the knowledge that you’re only hearing what the drivers are producing – and not what the room itself is bringing to the party. (Something you can learn more about in our six-part podcast series on the new Confidence).
The star of the show is the DDC Lens – a machined aluminium waveguide integrated into the precision Compex composite baffle . This ingenious part (the result of hundreds of hours of simulations, prototyping and listening tests) works in conjunction with the baffle shape, the tweeter and the midrange drivers (notice their brand-new Horizon Surround, also part of the system) and the woofers to focus sound waves where they need to go: you.
In fact, everything in the Confidence 60 is designed precisely for that purpose. Even the gasket that decouples the baffle from the cabinet, and the screws that hold everything in place.
The brand-new Esotar3 28mm soft-dome tweeter takes over 40 years of Dynaudio expertise, plus plenty of new learnings from development of the award-winning Esotar Forty unit – and rolls it all into the finest tweeter we’ve ever created. A powerful neodymium magnet system, innovations in airflow routing, the new resonance-busting Hexis inner dome … it all combines to increase detail, clarity and sensitivity.
The new 23cm NeoTec MSP woofers also have neodymium magnets under the hood, and use three layers of glass-fibre in their voice-coil formers for optimum stiffness. The voice-coils themselves are copper (which provides extra moving mass for tighter, more powerful and more controlled bass in this specific driver design). And the entire woofer motor has been designed to harness airflow using an innovative new venting system that’s been machined directly into the magnet.
The Confidence 60’s brand-new MSP midrange drivers are a big departure from previous Dynaudio designs.
They use a radical surround design – the Horizon – that follows the cone’s shape right to the edge of the driver. This reduces the surround’s first resonant mode to effectively increase the whole playing surface area and improve performance. They also sit flush with the baffle to reduce diffractions from the diaphragm and the adjacent tweeter.
Behind the scenes, the basket has been given a new lightweight organic design – one that’s resulted from extensive topology-optimisation simulations. It increases airflow, maintains its stability and rigidity and reduces weight simultaneously without sacrificing performance.
And it’s all finished in our trademark Danish-designed furniture-grade cabinetry. Perfect performance, perfect quality.
Specifications
Specification sheet for Confidence part 2Sensitivity:IEC power handling:Impedance:Frequency response (± 3 dB):Box Principle:Crossover:Crossover frequency:Crossover topology:Woofer:Midrange:Tweeter:
| 87dB (2.83V / 1m) |
| 600W |
| 4 Ω (Minimum 3.7 Ω @ 71Hz) |
| 29Hz–22kHz |
| Bass reflex, down-firing |
| 3 way |
| 200, 2580Hz |
| 2nd/3rd order with DDC |
| 2x23cm MSP |
| 2x15 cm MSP |
| 28 mm Esotar3 |
Specification sheet for Confidence part 1Weight:Dimensions (W x H x D):: Dimensions with feet/grille (W x H x D)::
| 66.2 kg/145.9 lbs |
| 271 x 1634 x 469 mm |
| 10 43/64 x 64 21/64 x 18 15/32 Inches |
| 432 x 1679 x 517 mm |
| 17 1/64 x 66 7/64 x 20 23/64 Inches |
