Product Infomation
 | | 제품명 | EVO3 Initium | | 카테고리 | 전원/차폐장치 |
EVO3 Initium은 매우 합리적인 가격으로 고품질의 성능을 제공하도록 설계된 IsoTek의 새 엔트리 레벨 전원 케이블입니다. |
 |  |
|
|
EVO3 Initium is IsoTek’s new entry level power cable designed to offer high quality performance at an extremely fair price. Initium is a must for replacing all of your free standard black plastic power leads which have been designed down to a price not up to a quality.
DESIGN
CONSTRUCTION: The conductors are in a parallel construction with a slight rotational twist. This established technique remains the first line of defence against RFI and EMI rejection.
A) Conductors: 99.9999% OFC conductors offer an exceptional level of purity with enhanced conductivity. They are less likely to fracture or degrade over time.
B) Dielectric: PE dielectric (insulation) is chemically inert and has a very low dielectric constant over a wide frequency range. PE possesses a very high degree of stress crack resistance and a low coefficient of friction making it an exceptional dielectric. PE is a good choice for safety in both temperature and electrical insulation.
C) Filler: Cotton filler has been used to give the cable internal strength and reduce microphony. Cotton also possesses excellent dielectric properties, the best of a solid material.
D) Wrap: A paper wrap is used to secure the construction prior to the application of a flexible PVC jacket. The addition of the paper and cotton form a buffer with the PVC so as to maintain exceptional dielectric properties.
E) Jacket: PVC is used as the outer jacket to give a high degree of flexibility and mechanical strength.
TERMINATION: Initium cable is terminated using IsoTek’s bespoke Audiophile grade moulded connectors of solid OFC. These offer good performance qualities.
Specifications
IsoTek Initium uses high quality materials with intelligent construction to deliver a power cable of outstanding performance and mechanical integrity, which will not degrade over time or break your bank balance.
Cable LengthOuter DiameterOuter JacketBarrier/WrapFillerInsulation/DielectricConductorsMaterialCapacitance Power Rating PropagationUnique TerminationSuitability
| 1.5m standard (no custom length) |
| 10mm |
| High flexibility PVC |
| Paper wrap |
| Cotton |
| Polyethylen (PE) |
| 3 x 2sqmm |
| 99.9999% Oxygen Free Copper |
| 16 Amp |
| Terminated with bespoke audiophile-grade connectors with robust nickel plating |
| Suitable for CD players, preamps, tuners, power amps, Blu-ray players, music servers, TVs, soundbars and more! |
EVO3 Initium은 매우 합리적인 가격으로 고품질의 성능을 제공하도록 설계된 IsoTek의 새 엔트리 레벨 전원 케이블입니다.
EVO3 Initium is IsoTek’s new entry level power cable designed to offer high quality performance at an extremely fair price. Initium is a must for replacing all of your free standard black plastic power leads which have been designed down to a price not up to a quality.
DESIGN
CONSTRUCTION: The conductors are in a parallel construction with a slight rotational twist. This established technique remains the first line of defence against RFI and EMI rejection.
A) Conductors: 99.9999% OFC conductors offer an exceptional level of purity with enhanced conductivity. They are less likely to fracture or degrade over time.
B) Dielectric: PE dielectric (insulation) is chemically inert and has a very low dielectric constant over a wide frequency range. PE possesses a very high degree of stress crack resistance and a low coefficient of friction making it an exceptional dielectric. PE is a good choice for safety in both temperature and electrical insulation.
C) Filler: Cotton filler has been used to give the cable internal strength and reduce microphony. Cotton also possesses excellent dielectric properties, the best of a solid material.
D) Wrap: A paper wrap is used to secure the construction prior to the application of a flexible PVC jacket. The addition of the paper and cotton form a buffer with the PVC so as to maintain exceptional dielectric properties.
E) Jacket: PVC is used as the outer jacket to give a high degree of flexibility and mechanical strength.
TERMINATION: Initium cable is terminated using IsoTek’s bespoke Audiophile grade moulded connectors of solid OFC. These offer good performance qualities.
IsoTek Initium uses high quality materials with intelligent construction to deliver a power cable of outstanding performance and mechanical integrity, which will not degrade over time or break your bank balance.
Cable LengthOuter DiameterOuter JacketBarrier/WrapFillerInsulation/DielectricConductorsMaterialCapacitance Power Rating PropagationUnique TerminationSuitability
