Product Infomation
 | | 제품명 | EVO3 Mosaic Genesis | | 카테고리 | 전원/차폐장치 |
EVO3 Mosaic Genesis는 IsoTek의 Ultimate 시리즈의 하이브리드형 버전입니다. |
 |
|  |
|
The EVO3 Mosaic Genesis is a hybridised version of IsoTek’s Ultimate series. Combining the extremely low THD sine wave generation engine from Genesis and a lighter version of Super Titan’s Direct-Coupled© conditioning network, it delivers the perfect balance between power and performance.
- Removes both Common Mode and Differential Mode mains noise.
- Medium power: (three outlets provide new sine wave generation) exceeds 85dB of noise reduction, extending to zero Hz. High current: (two outlets) offers extremely low- impedance and RFI reduction of 75dB (50 ohms standard).
- 99,000A progressive protection circuit.
- Internal wiring; solid core silver plated PCOCC with FEP virtually an air dielectric.
- 150W of totally clean power for front-end components (three outlets) combined.
- With 4600W (230V @ 20A) for large power amplifiers and mono blocks (two outlets). Combining a single cell mains sine wave generator cell from Genesis combined with a light version of the unique Direct-Coupled© conditioning network of Mosaic Titan.
- Available with UK, EU, US, Australian, Swiss and South African outlets.
Specifications
Number of outletsOutlets 1-3 (sine wave generation)Outlets 4-5 (high current)Mains inletMains voltageMains frequencyDimensionsWeight (boxed)
| 5 |
| 150W |
| 3680W |
| 16A IEC C20 |
| 100 to 240V depending upon model |
| 50 to 60Hz depending upon model |
| 225 x 225 x 470mm (W x H x D) |
| 20Kg |
EVO3 Mosaic Genesis는 IsoTek의 Ultimate 시리즈의 하이브리드형 버전입니다.
The EVO3 Mosaic Genesis is a hybridised version of IsoTek’s Ultimate series. Combining the extremely low THD sine wave generation engine from Genesis and a lighter version of Super Titan’s Direct-Coupled© conditioning network, it delivers the perfect balance between power and performance.
Number of outletsOutlets 1-3 (sine wave generation)Outlets 4-5 (high current)Mains inletMains voltageMains frequencyDimensionsWeight (boxed)
